Technical Specifications
| Number of channels | 59 |
|---|---|
| Rated current | 15A/14 channels; 3A/3 channels; Signal 42 channels |
| Rated voltage | 0-380VAC/DC |
| Insulation resistance | ≥500MΩ/1000VDC |
| Insulation strength | 1500VAC@50HZ,60S |
| Dynamic contact resistance | ≤30MΩ |
| Static contact resistance | Power ≤60MΩ, signal ≤120MΩ |
| Rotational torque | ≤0.3N.m (full temperature) |
| Electrical contact material | Precious metals |
| Structural material | Aluminum alloy |
| Operating speed | 0-250rpm |
| Operating temperature | -40℃~+80℃ |
| Protection rating | IP51 |
| Wavelength | 850-1310/1310-1650nm |
| Number of optical | 1 |
| Optical insertion loss | ﹤2dB |
| Return loss | ﹥50dB |
| Connector type | FC |
Drawing
