Technical Specifications
| Number of Channels | 16 |
|---|---|
| Rated Current | 4A/channel (4 channels); 1A/channel (12 channels) |
| Rated Voltage | 1-4 channels: 0-600VAC; 5-16 channels: 0-380VAC |
| Insulation Resistance | 1-4 channels: ≥1000MΩ/1000VDC; 5-16 channels: ≥500MΩ/1000VDC |
| Insulation Strength | 1-4 channels: 2500VAC@50HZ, 60S; 5-16 channels: 500VAC@50HZ, 60S |
| Dynamic Contact Resistance Variation | ≤10MΩ |
| Electrical Contact Material | Precious Metals |
| Structural Material | Stainless Steel |
| Operating Speed | 0-250rpm |
| Operating Temperature | -40℃~+80℃ |
| Protection Rating | IP65 |
| Wavelength | 1310/1550nm |
| Number of Optical Paths | 2 |
| Optical Insertion Loss | ﹤2dB |
| Return Loss | ﹥60dB |
| Connector Type | FC |
Drawing
